Brand: UKO
Code: SPMG
Features: The insert has strong anti-wear performance…
SPMG Shallow Drilling Inserts
Categories: Holemaking, Indexable Insert Drills, Metal Cutting Tools
Tags: CNC carbide, SPMG, SPMG insert, U drills inserts
Description
Features:
- The insert has strong anti-wear performance.
- SPMG insert has 4 cutting edges, more economical.
- Strong geometry design for rough cutting in steel, alloy steel and hardened steel.
- Suitable for stainless steel, steel processing.
- Insert for T-Drill on the application of Cast iron drilling.
Specifications:
| Insert Shape | Type | Dimension | ||||
| L | ΦI.C | S | Φd | RE | ||
![]() |
SPMG050204 | 5 | 5 | 2.38 | 2.25 | 0.4 |
| SPMG060204 | 6 | 6 | 2.38 | 2.61 | 0.4 | |
| SPMG07T308 | 7 | 7 | 3.97 | 2.85 | 0.8 | |
| SPMG090408 | 9 | 9 | 4.3 | 4.05 | 0.8 | |
| SPMG110408 | 11 | 11 | 4.8 | 4.5 | 0.8 | |
| SPMG140512 | 14 | 14 | 5.2 | 5.75 | 1.2 | |
Additional information
| Turning insert shape | SPMG |
|---|
