Tungsten Carbide Strips
Carbide strip is one of many tungsten carbide materials, which is named for its rectangular plate. It is mainly made of WC tungsten carbide and co cobalt powder mixed by metallurgical methods through pulverization, ball milling, pressing and sintering. The component contents of WC and CO in cemented carbide strips for different purposes are different, and the application range is very wide.
We provide cemented carbide strip, It has excellent characteristics of excellent rigidity, high hardness, good wear resistance, high elastic modulus, high compressive strength, good chemical stability (acid resistance, alkali resistance, high-temperature oxidation), low impact toughness, low expansion coefficient, and similar heat conduction and conductivity with iron and its alloys. It has a brand that is especially suitable for manufacturing reversible woodworking blades. It has very good performance in quality, such as wear resistance (not needing frequent grinding), impact resistance and long service life. It greatly improves the production efficiency of customers and has been recognized by many customers.
| Grade | Co
(%) |
Grain size (um) | Hardness (HRA) | Density (g/cm3) | Bending strength (MPa) | Modulus of elasticity (GPa) | Coefficient of thermal expansion 10/C | Scope of application |
| ST05B | 6.5 | 1 | 91.5 | 14.8 | 2800 | 525 | 4.9 | Suitable for processing solid wood, MDF, gray cast iron, non-ferrous metal materials, etc. |
| ST10C | 7 | 1 | 90.5 | 14.8 | 2800 | 520 | 5 | Strong applicability, suitable for processing solid wood, MDF, gray cast iron, non-ferrous metals and other materials. |
| ST10B | 8 | 1 | 91 | 14.6 | 3000 | 510 | 5.1 | Good comprehensive performance, suitable for processing solid wood, MDF, gray cast iron, chilled cast iron, stainless steel, non-ferrous metals and other materials. |
| ST03F | 5 | 0.6 | 93.5 | 14.9 | 2600 | 540 | 4.8 | Ultra-fine grain, good corrosion resistance, high hardness, high wear resistance, suitable for cutting tools with characteristics of corrosive media, bamboo and wood cutting tools, cold-hardened cast iron, hardened steel, PCB, and braking materials. |
| ST10F | 6 | 0.6 | 93 | 14.8 | 3000 | 530 | 4.9 | Ultra-fine grain, suitable for making simple shapes of woodworking tools and cutting tools of chilled cast iron, hardened steel, PCB, brake materials. |
| ST15F | 10 | 0.6 | 92.2 | 14.4 | 3300 | 490 | 5.4 | Ultra-fine grain, excellent comprehensive performance, good wear resistance and weldability, suitable for the processing of solid wood, MDF, particle board and other wood and cold-hardened cast iron hardened steel, PCB, fiber reinforced materials precision and rough machining |
| ST12F | 9 | 0.5 | 93.6 | 14.5 | 4000 | 510 | 5.3 | Super fine grain, high red hardness, suitable for processing high speed steel, tool steel, cold hard cast iron, fiberglass, particle board and stainless steel. |
| ST05F | 6 | 0.6 | 93 | 14.9 | 3200 | 530 | 4.9 | Super fine grain, high hardness, high wear resistance, suitable for bamboo and wood knives. |
Resource
Related Products
Cemented carbide strips are mainly made by mixing WC tungsten carbide and Co cobalt powder by metallurgy, milling, pressing, sintering. The main alloy composition is WC and Co. WC in cemented carbide strips for different purposes It is not consistent with the composition content of Co, and is widely used.
One of the many materials of cemented carbide strips, which is named for its rectangular plate (or square), also known as cemented carbide strips.
Process flow
Milling → Formulation according to application requirements → Wet grinding → Mixing → Crushing → Drying → Screening → After adding the molding agent → Redrying → Screening to obtain the mixture → Granulation → Pressing → Forming → Low-pressure sintering → Forming (blank ) → Flaw inspection → Packaging → Storage.
Performance characteristics
Cemented carbide strips have excellent hardness, high hardness, good wear resistance, high elastic modulus, high compressive strength, good chemical stability (acid resistance, alkali resistance, high-temperature oxidation), low impact toughness, and expansion coefficient Low, thermal conductivity and electrical conductivity are similar to iron and its alloys.
How to buy carbide strips?
The tungsten carbide strips are generally purchased from these aspects:
- The compactness of the cemented carbide strips;
- Abrasion resistance of cemented carbide strips;
- The impact resistance of the carbide strips;
UKO’s hard alloy strips use cold isostatic pressing and low-pressure sintering technology to ensure that the strips are free of trachoma and pores, are not easy to crack during cutting, and have good wear resistance and strong impact resistance.
What is the use of carbide strips?
Carbide strips are mainly composed of WC tungsten carbide and Co cobalt powder mixed by metallurgical methods through powdering, ball milling, pressing, and sintering. The main alloy components are WC and Co. The content of ingredients is not consistent with that of Co, which makes it widely used. One of the many materials of cemented carbide strip is named after its rectangular bar shape, also known as cemented carbide strip bar.
Carbide strip performance:
Carbide strips have excellent warp hardness, high hardness, good wear resistance, high elastic modulus, high internal compressive strength, good chemical stability (acid resistance, alkali, high temperature oxidation), low impact toughness, expansion The coefficient is low, and the characteristics of thermal conductivity and electrical conductivity are similar to those of iron and its alloys.
Carbide strip application range:
Carbide strips have the characteristics of high red hardness, good weldability, high hardness, and high wear resistance. They are mainly used in the production of woodworking reversible knives, MDF, gray cast iron, non-ferrous metal materials, chilled cast iron, hardened steel, PCB, brake material. When using it, you should select the hard alloy strip with suitable material according to the application.
